Dimensions
Dimensi
mm


Wheelbase
Jarak Sumbu Roda

3,350
Overall Length
Panjang Keseluruhan

5,750
Overall Width
Lebar Keseluruhan

1,750
Overall Height
Tinggi Keseluruhan

2,110
Ground Clearance
Tinggi Minimal dari Tanah

200
Tread Front
Jarak Roda Depan Kiri Kanan

1,390
Tread Rear
Jarak Roda Belakang Kiri Kanan

1,380
Weights
Berat
kg


Kerb Weight
Berat Chassis Termasuk Kabin

2,055
GVW
GVW

5,200
Performance
Kemampuan
m


Min. Turning Radius
Radius Putar Minimum

7
Tire and Wheels
Roda



Tire Size
Ban

7.50 - 15 - 12PR
Wheel Size
Velg

15 x 5.50F-50-4.5t, 6 stud, 2 pieces
Engine
Mesin



Model
Model

4D34-2AT5
Type
Tipe

4 stroke-cycle water cooled direct injection diesel engine, with turbo intercooler
No. of Cylinder
Jumlah Silinder

4 in line
Bore and Stroke
Diameter x Langkah

104 mm x 115 mm
Piston Displacement
Isi Silinder

3,908 cc
Max. Output
Daya Maksimum
PS/rpm
110 / 2,900 rpm
Max. Torque
Torsi Maksimum
Kgm/rpm
28 / 1,600 rpm
Transmission
Transmisi



Model
Model

M025S5
Type
Tipe

5 - forward and 1 - reverse speed, 1st to 5th, syncromesh, rev. constantmesh gears
Ratio
Perbandingan Gigi

5.181 - 2.865 - 1.593 - 1.000 - 0.739
Rev. 5.181
Clutch (type, model)
Kopeling

Hydraulic control single dry plate
C3W28D
Axle
As



Front Axle
Depan

Reverse Elliot, "i" beam type
Rear Axle
Belakang

Full floating type
Final Gear Ratio
Perbandingan Gigi Akhir

5.714
Steering
setir






Ball nut type with power steering, Tilt & telescopic steering column
Suspensions
Suspensi



Front
Depan

Semi elliptic, laminated leaf springs with Hydraulic double acting telescopic type
Rear
Belakang

Semi elliptic, laminated leaf springs with Hydraulic double acting telescopic type
Brakes
Rem



Service
Rem Kaki

Hydraulic with vacuum servo assitance, dual circuit
Parking
Rem Tangan

Internal expanding type at rear of transmission
Auxiliary
Rem Pambantu

Exhaust brake
Batteries
Accu






24 V, 60 AH (N50Z)
Fuel Tank
Kapasitas Tangki Solar






100 liters
